Spec sheet
| Frequency range | 6.000～60.000 |
| Vibration mode | 6.000～30.000MH Fundamental 27.000～60.000MH 3rd Overtone |
| Excitation power | 0.1 TYPICAL |
| Load capacitance | 8pF～32pF of Series |
| Adjust the frequency difference | ±10、±30、±50（at 25℃） |
| Electrostatic capacitance | 7 MAX |
| Operating temperature range | 0℃～+70℃ Standard |
| Frequency stability | ±30ppm Standard |
| Storage temperature range | -40℃～+85℃ |
| Aging rate | ±5ppm（at 25℃） |
Equivalent series resistor
Frequency Range(MHz) | ESR MAX(Ω) | Frequency Range(MHz ) | ESR MAX(Ω) |
6.000～6.999 | 100 | 13.000～19.999 | 50 |
7.000～8.999 | 80 | 20.000～30.999 | 30 |
9.000～12.999 | 60 | 27.000～60.000 | 100 |
Note: Special requirements can be processed according to user needs.
